Curtainsiders

Austruck curtainsiders are manufactured in all types and sizes to suit your needs. We manufacture curtainsiders for many different industries including plant nurseries, courier companies and dry goods transport companies. Our unique one hand roller bearing curtain system is equipped with stainless steel buckles and plastic coated hooks. Mezzanine floors are fully removable and adjustable. Austruck Curtainsiders are custom built to all your requirements.

Some of our specifications are:

• Front Wall: 150mm Engineered front wall which meets all load restraint requirements, fitted with heavy duty aluminium
• (Structure Flex) Tensioners.
• Rear Frame: Channel uprights fitted with dock rubbers & under run bar.
• Roof Section: All aluminium structured double track to accommodate sliding gates if required. Aluminium roof bows with a
• Bonded pre-stressed 1 piece aluminium roof skin, keeping body weight to a minimum, for maximum payload.
• Safety OHS: Side non slip safety footsteps fitted to each corner. Safety handles fitted to the front and rear.
• Floor Frame: 100mm x 50mm main runners fitted with 75mm x 50mm RHS cross bearers at 400mm apart.
• Rear Doors: Double rear FRP panel doors, 4 hinges with 1 heavy duty large camlock per door.
• Floor and coaming: Checker plate floor with 100mm x 45mm RSJ coamings and 20mm lip above the floor sheet.
• Curtains: Easy slide curtain system 980 gram polymer, with double roller system with quick release stainless steel buckles at 600mm apart;
• All straps are fitted with plastic coated hooks. 1 sliding removable centre post fitted to each side.
• Gates: Light weight lift-out gates 1500mm high.
•  Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting: Halogen work lamps, Hella LED clearance lamps fitted, top – front, rear, side, and blinker.

Optional Extras:

• Curtains: Load rated curtains at 1500kg per pallet space No gates required.
• Rear tensioners: Rear curtain tensioners (structure flex).
• Load Restraint: Sliding load binders in track.
• Gates: Sliding gates suspended by single chain in lieu of lift-out gates.
• Floor: 5mm Checker plate floor.
• Mezzanine decks: Mezzanine floor with see through floors  (2 sections ) & and load binders to suit.
• Safety: Reversing camera system 130mm colour monitor.
• Storage: Steel under chassis tool box.
• Nose-cone: Fibreglass flush mounted.
• Tailgate Lifters, Tow Bars.
• Curtain Imaging, graphic designs, cab recolour.

Trailers

Austruck is fast becoming a one stop work shop, with Truck and Trailer Combo’s custom built to suit all your requirements.

Our range includes Pig trailers, Dog trailers, Super Dogs, Flat deck trailers, Curtainsiders, Twist Lock Dogs, Skel Trailers, Mezzanine Decks and a host of other configurations of trailers for your business. Health and safety is a big part of our business and our range of safety equipment includes, safety steps and hand rails, non slip treads, standard gates, and curtain gate retainer systems. The auto release curtain buckle system and tail gate loaders all conform to Australian OH&S standards.

Car Carriers

We offer both 3 car carriers and beaver tail tray bodies for all your automotive cargo needs.

Beaver Tail Trailer

• Front of trailer is semi circular shape to suit tray , ( no ramps needed )
• Heavy duty fabricated chassis beams.
• “A” frame draw bar, to suit slide plate, complete with 16mm safety chains.
• 2 wind down landing legs fitted to main rails.
• Drum brake, grease filled axle on air suspension.
• Air weigh gauge.
• 215/75R 17.5” Bridgestone tyres fitted to 6.50 x 17.5” 8 stud steel rims.
• 100 x 50 channel side coaming fitted flush with 3mm checker plate floor and TNT quick lash.
• TNT quick lash system.
• 900mm long toolbox c/w stainless steel “T” lock.
• Rear fitted with under run bumper.
• All compulsory mud guards, reflectors & marker plates.
• L.E.D. tail lights, front clearance & side clearance lamps 4 per side , and blinker to suit States regs.
• Painting: 2 pack white.
• 2 hydraulic or manual slide out ramps fitted to rear behind light panel.

3 Car Carrier

• Floor frame: Heavy duty main runners fitted with 75mm x 50mm RHS cross bearers fitted at 400mm apart with 3mm checker plate floor.
• Side coamings: 100mm x 50mm channel fitted flush with floor sheet .
• Rear: To suit small fifth wheel or Bartlett Ball with air brakes to rear.
• Rear: Of trailer is a semi circular shape to suit trailer , ( no ramps needed )
• Steps: Safety side steps with non slip foot hold at each corner where possible.
• Head board: Shaped frame head board set 50mm above cab
• Tie downs: TNT type floor quicklash system.
• Tool box: 900 x 400 x 400 with drop chains & stainless steel lock and painted black.
• Floor boxes: 2 in floor at front to store straps.
• Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting: LED front clearance, & side clearance lamps 3 per side and 2 red rear clearance lamps.
• Painting: 2 pack white and under body black.

Colorbond Vans

• Floor Frame: Heavy duty main runners fitted with 75mm x 50mm RHS cross bearers fitted at 400mm apart.
• Floor sheeting : 3mm to 5mm Checker plate or timber.
• Rear Frame: 50mm x 50mm RHS Fitted with under run bar & step or bump rubbers.
• Frame Work: 30mm x 30mm RHS tube fitted with 4 tie rails, 150mm high bottom kick panel.
• Roof Frame: Fully aluminium structured roof with Aluminium roof bows and a bonded prestressed 1 piece aluminium roof skin, keeping
  body weight to a minimum, giving you more payload.
• Rear Doors: Double rear FRP panel doors fitted with seals, 4 hinges and 1 heavy duty camlock per door fitted with door catches & smash panels.
• Sheeting: Sign white colour bond over – off white plywood fix to frame work.
• Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting: Hella Led front clearance, & side clearance lamps and 2 red rear clearance lamps.
• Interior flood lamp fitted in top rear of body.
• Painting: All paint work on back frame are painted in high quality primer and two pack white gloss over steel work to eliminate rust around
• Doorways and under body will be painted in black.

Optional Extras:

• Floor: 5mm Checker plate or smooth, 19mm Tongue and groove, 18mm Hypo-grip.
• Side Doors: Pallet width doors, single or double. Toddco roller door. Aluminium flat slat roller door.
• Nose Cone: Fibreglass flush mounted.
• Walk Board: 2400mm long slide out walk board with in floor storage.
• Tail Board: Full width Tail board with springs and chains.
• Load Restraint: Shoring track and bars.
• Tool Box: Under chassis steel storage boxes.
• Tailgate Loaders and Tow Bars.
• Body Imaging with your Company name or Logo.

FRP Vans

• Front wall and Side walls: 20mm FRP panel white in color with 300mm gal kick panel.
• Rear frame : 50mm uprights fitted with dock rubber & under run bar or step
• Rear: Pillars are fitted with hand safety rail each side of door way
• Rear Doors: Double rear panel doors fitted with seals, 4 hinges and 1 heavy duty large camlock per door fitted with turn signs and door catches.
• Roof section: Aluminum roof bows fitted with pre-stressed 1 piece aluminum roof skin, Aluminum extrusions polished, external bottom, top and front rails fitted off with heavy duty polished aluminum cast corner caps.
• Floor frame: 100mm x 50mm channel main runners fitted with 75mm x 50mm RHS cross bearers fitted at 400mm apart.
• Floor sheeting : 3mm Checker plate
• Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting: Work lamp Halogen 55 watt fitted at rear back corner, switch in rear No. plate panel or optional to have in body.
• L.E.D: 3 side clearance lamps fitted, 2 front top corner clearance lamps, 2 rear top red clearance lamps.

Optional Extras:

• Nose cone: Fibreglass flush mounted on front wall.
• Rear Step: Full with 200mm checker plate step.
• Shoring tracks: 2 per wall with 2 bars to suit width, shoring bar storage at top rear.
• Floor: Choice of 5mm steel checker plate, 19mm tongue and groove hardwood, 18mm Hypo-Grip timber.
• Battens: Dressed timber or carpet covered battens.
• Nose Cone: Fibreglass flush mounted.
• Side Door: 900mm Door, Pallet width- single or double with recessed locks.
• Rear Doors: Toddco roller door, Aluminium Flat slat roller door, Zinc roller door.
• Walk Board: 2400mm slide out walk board, stored under floor.
• Tail Board: Full width tailboard with spring and chains.
• Load Restraint: Shoring Track and shoring bars.
• Tool Boxes: Steel, under chassis tool boxes. Several sizes available.
• Tow Bars, Tailgate loaders.
• Body Imaging with your Company name or Logo.

Dog Trailers

Dog Trailers can be manufactured to suit your existing truck configuration including matching imaging. Our truck and trailer combos are custom built to your requirements. We also manufacture Pig trailers in any axle configurations, Super dogs, Flat deck, Twist lock dogs, Skel trailers, Mezzanine decks and many other configurations.

Insulated Vans

Austruck’s Sandwich Pack Insulated Vans support temperatures from 0°C to 4°C

• Front wall: 75mm thick Colorbond Sandwich pack construction
• Side walls: 50mm thick Colorbond Sandwich pack construction
• Roof:75mm thick Colorbond Sandwich pack construction
• Rear Frame: 75mm x 50mm, fitted with under run bar & step or bump rubbers.
• Floor Frame: 100mm x 50mm main runners fitted with 75mm x 50mm RHS cross bearers fitted at 400mm apart with 21mm timber fastened to bearers, 600 oz fibre-glass over timber the flow coat finish
• Floor Insulated urethane: 65mm thick sprayed under floor for that better thermal cover.
• Rear doors: 75mm thick double rear sandwich pack doors fitted with black rubber seals, 3 hinges and 1 heavy duty camlock per door fitted with door catches & smash panels.
• Safety: Handles fitted at doorways and rear pillars.
• Aluminium Extrusion: Polished large aluminium angle & large bottom rail extrusions specifically designed for strength and enhance appearance of body.
• Paint: All paint work on back & side frames are painted in high quality two pack white gloss over steel work to eliminate rust around doorways & under body will be painted in black.
• Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting: 3 Interior bright lamps fitted to roof.
• L.E.D: 3 Side clearance lamps fitted, 2 front top corner clearance lamps, 2 rear top red clearance lamps.

Optional Extras

• Floor: 3mm or 5mm Aluminium checker plate over fibreglass. 28mm container plywood floor.
• Side Doors: 75mm sandwich pack door 900mm wide. Pallet width single or double doors, with 1 cam lock per door.
• Rear Doors: Triple rear doors with 1 cam lock per door, Toddco ( Polar) 65mm insulated roller door.
• Bulk Head: Fully insulated sliding wall and Fan kit for multi- temp compartments.
• Door Curtains: Rear and side cold curtains to help maintain temperature when doors are open.
• Load Restraint: Shoring track and shoring bars.
• Tailgate Loaders: Full range of tail lifts to suit your requirements.
• Refrigeration: Range of small engine drive fridge units up to large Diesel and electric.
• Body Imaging with your Company name or Logo.

Our Styro-foam Insulated Van supports temperatures up to -18°C

• Front wall: 100mm thick Styro-foam Sandwich pack construction
• Side walls: 50mm thick Styro-foam Sandwich pack construction
• Roof: 100mm thick Styro-foam Sandwich pack construction
• Rear Frame: 75mm x 50mm, fitted with under run bar & step or bump rubbers.
• Floor Frame: 100mm x 50mm main runners fitted with 75mm x 50mm RHS cross bearers fitted at 400mm apart with 21mm timber fastened to bearers, 600 oz fibre-glass over timber the flow coat finish
• Floor Insulated urethane: 65mm thick sprayed under floor for that better thermal cover.
• Rear doors: 75mm thick double rear sandwich pack doors fitted with black rubber seals, 3 hinges and 1 heavy duty camlock per door fitted with door catches & smash panels.
• Safety: Handles fitted at doorways and rear pillars.
• Aluminium Extrusion: Polished large aluminium angle & large bottom rail extrusions specifically designed for strength and enhance appearance of body.
• Paint: All paint work on back & side frames are painted in high quality two pack white gloss over steel work to eliminate rust around doorways & under body will be painted in black.
• Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting: 3 Interior bright lamps fitted to roof.
• L.E.D: 3 Side clearance lamps fitted, 2 front top corner clearance lamps, 2 rear top red clearance lamps.

Optional Extras

• Floor: 3mm or 5mm Aluminium checker plate over fibreglass. 28mm container plywood floor.
• Side Doors: 75mm sandwich pack door 900mm wide. Pallet width single or double doors, with 1 cam lock per door.
• Rear Doors: Triple rear doors with 1 cam lock per door, Toddco ( Polar) 65mm insulated roller door.
• Bulk Head: Fully insulated sliding wall and Fan kit for multi- temp compartments.
• Door Curtains: Rear and side cold curtains to help maintain temperature when doors are open.
• Load Restraint: Shoring track and shoring bars.
• Tailgate Loaders: Full range of tail lifts to suit your requirements.
• Refrigeration: Range of small engine drive fridge units up to large Diesel and electric.
• Body Imaging with your Company name or Logo.

Fibreglass Freezer Insulated Vans support temperatures up to -25°C

• Front wall: Moulded fibreglass skins bonded over a ridge polyurethane foam core (100mm thick) with pultrusion reinforcement every 600mm.
• Aperture: For refrigeration unit and mounting frame to suit your Carrier unit.
• Rear Frame: Hot dipped galvanised rear frame fitted with bump rubbers.
• Roof: Moulded fibreglass skins bonded over a rigid polyurethane foam core (100mm thick) with pultrusion reinforcement every 600mm.
• Side Walls: Moulded fibreglass skins bonded over a rigid polyurethane foam core (40mm thick) with pultrusion reinforcement every 600mm.
• Floor: 100mm flat non-slip fibreglass floor over 21mm hardwood plywood, reinforced and bonded to 65mm polyurethane foam insulation under side of floor.
• Polished rails: Heavy duty top and bottom aluminium rails and corner caps
• Kick Panels: 3mm thick galvanised steel 300mm high all around interior.
• Doors: Double rear door fitted with heavy duty hinges and camlocks.
• Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting: 3 Interior bright lamps fitted to roof.
• L.E.D: 3 Side clearance lamps fitted, 2 front top corner clearance lamps, 2 rear top red clearance lamps.

Optional Extras

• Floor: 3mm or 5mm Aluminium checker plate over fibreglass. 28mm container plywood floor,.
• Air flow floor system, for better circulation and constant temperature.
• Pallet Skids: 4 Rows of Aluminium Pallet skids.
• Side Doors: pack door 900mm wide. Pallet width single or double doors, with 1 cam lock per door.
• Rear Doors: Triple rear doors with 1 cam lock per door, or Toddco ( Polar) 65mm insulated roller door.
• Bulk Head: Fully insulated sliding wall and Fan kit for multi- temp compartments.
• Door Curtains: Rear and side cold curtains to help maintain temperature when doors are open.
• Load Restraint: Shoring track and shoring bars.
• Tailgate Loaders: Full range of tail lifts to suit your requirements.
• Refrigeration: Range of small engine drive fridge units up to large Diesel and electric.
• Storage: A range of tool boxes to suit your requirements.
• Body Imaging with your Company name or Logo.

Maxi Light Van

• Front wall and Side walls: 21mm Maxi light panel white in color with 300mm gal kick panel.
• Rear frame : 50mm uprights fitted with dock rubber & under run bar or step
• Rear: Pillars are fitted with hand safety rail each side of door way
• Rear Doors: Double rear panel doors fitted with seals, 4 hinges and 1 heavy duty large camlock per door fitted with turn signs and door catches.
• Roof section: Aluminum roof bows fitted with pre-stressed 1 piece aluminum roof skin, Aluminum extrusions polished, external bottom, top and front rails fitted with heavy duty polished aluminum cast corner caps.
• Floor frame: 100mm x 50mm channel main runners fitted with 75mm x 50mm RHS cross bearers fitted at 400mm apart.
• Floor sheeting : 3mm or 5mm Checker plate , or timber .
• Mudguards: All compulsory mud guards, reflectors & marker plates.
• Lighting : Work lamp Halogen 55 watt fitted at rear back corner , switch in rear Number plate panel or optional to have in body.
• L.E.D: 3 side clearance lamps fitted, 2 front top corner clearance lamps, 2 rear top red clearance lamps.

Optional Extras:

• Floor: 5mm steel checker plate, 19mm Tongue and groove hardwood, 18mm Hypo-grip timber.
• Side Doors: Single door 900mm wide, single or double pallet width side door 1370mm wide.
• Rear Doors: Triple rear doors with 1 cam lock per door, Toddco roller door, Aluminium flat slat roller door, Zinc roller door.
• Nose Cone: Fibreglass flush mounted.
• Walk Board: 2400mm slide out walk board stored under the floor.
• Tail Board: Full width walk board with spring and chains.
• Load restraint: Shoring track and bars.
• Tailgate Loaders: Full range of tail lifts to suit your requirements.
• Storage: A range of tool boxes to suit your requirements.
• Body Imaging with your Company name or Logo.

Beverage Body Restrainer Slider

Austruck’s beverage body restrainer slider is built to suit all type of beverage and food delivery. We custom build to your design, come in and discuss your requirements, so before you decide, see us first for competitive pricing and quality workmanship. We have built for some of the most popular brands in Australia in our state of the art modern factory.

Insulated Curtainsider

• Front wall insulated :150 mm Engineered front wall with heavy duty front Aluminium tensioners. Front wall is fitted with 600mm checker plate pallet protection & sheeted above.
• Rear frame : 100mm channel uprights fitted with dock rubbers & under run bar.
• Safety OHS : Side non slip safety footsteps fitted to each corner, safety handles on front wall, rear fitted with handles and non slip safety footing.
• Roof section : Fully insulated with 75mm sandwich and Aluminium structure double track to accommodate sliding gates if needed and fitted with a pre-stressed 1 piece aluminium roof skin bonded. Fitted with one sliding post to suit.
• Floor frame : 100mm x 50mm main runners fitted with 75mm x 50mm RHS cross bearers fitted at 400mm apart and fully insulate under bearers with urethane .
• Floor sheet : 3mm or 5mm Checker plate
• Side coaming: 100mm x 45mm RSJ Fitted with 20mm lip above floor sheet.
• Gates : 4 Per side 1500 High light weight lift out gates
• Rear doors : Double rear FRP panel doors fitted with seals , 4 hinges and 1 heavy duty large camlock per door fitted with turn signs and door catches.
• Curtains insulated : Easy slide curtain system (890 Gram Polymar material) fitted with double roller system for that easy slide opening ,center lugs fitted to eliminate curtain bellowing.
• Curtain buckles : Quick release Stainless steel buckles at 600mm apart all straps fitted with plastic coated hooks.
• Mudguards : All compulsory mud guards, reflectors & marker plates.
• Lighting : Work lamp Halogen 55 watt fitted at rear top corner , Hella L.E.D. clearance lamps fitted front top , 2- rear top clearance, & 4 side clearance lamps per side.

Optional Extras:

• Insulated Load rated Curtains: 1500kg per pallet space load curtains (no gates required) with all load rated curtains, sliding posts are fitted at no more than 3mtr centres.
• Tool box: Steel 1200 x 500 x 500 with stainless steel Tee lock, mount passenger side.
• Tailgate Loaders: Variety of tailgate loaders to suit your requirements.
• Fridge Units: Small off engine drive units to large Diesel and electric models.
• Curtain Imaging, graphic designs, cab recolour.

Tippers

Tipping Tray

• Floor Frame: 125mm x 65mm Channel main runners with 75 x 50 RHS cross bearers fitted at 400mm apart with 5mm checker plate floor.
• Side Coamings: 100mm x 45mm RSJ, fitted 20mm above floor sheet and sweep out rear.
• Head Board: Solid H Head Board.
• Rear Panel: Short to suit rear lamps with mesh protection.
• Hydraulics: Single or Twin under body Ram with PTO with electric switches in cab.
• Safety: Under body Safety prop with hose burst valve.
• L.E.D: 2 side clearance lamps fitted 2 front top corner clearance lamps, 2 rear top red clearance lamps.
• Mudguards: All compulsory mudguards, reflectors and marker plates.

Optional Extras:

• Storage: A range of tool / storage boxes to your requirements.
• Tow Bars, Brake controllers, Voltage reducers.
• Load Restraint: Sliding binders in track with 9mtr straps fitted to passenger side.
• Safety: Flashing Beacons, Sign Boards, Arrow Boards.
• All Council specifications and requirements.
• Cranes: Front or rear mounted cranes.

Tub Tippers

• Floor Frame: 125mm x 65mm Channel main runners.
• Head Board: Solid to Tub.
• Floor: 5mm Flat sheet floor.
• Tail Gate: 2 or 3 way gate (with air opening)
• Rear Panel: Short to suit rear lamps with mesh protection.
• Hydraulics: Single, Twin under body or Well mounted ram with PTO with electric switches in cab.
• Safety: Under body Safety prop with hose burst valve.
• L.E.D: 2 side clearance lamps fitted 2 front top corner clearance lamps, 2 rear top red clearance lamps.
• Mudguards: All compulsory mud guards, reflectors & marker plates.

Optional Extras:

• Storage: A range of tool / storage boxes to your requirements.
• Tow Bars, Brake controllers, Voltage reducers.
• Tarp systems. Manual or motorised load covers.
• Safety: Flashing Beacons, Sign Boards, Arrow Boards.
• All Council specifications and requirements.

Dropside Tippers

• Floor Frame: Channel main runners with 75 x 50 bearer, finish with 3mm or 5mm floor.
• Head Board: Over top head board solid to top with window with mesh and shovel mounts
• Tail Gate: 2 or 3 way gate (side and up) with or without air gate lock.
• Drop Sides: Drop sides or fixed to suit your high x 3mm with heavy duty throw over catches.
• Rear Panel: Short to suit rear lamps with mesh protection over rear lamps.
• Hydraulics: Well mounted , Single or Twin under body Rams with PTO with electric switches in cab.
• Safety: Under body Safety prop one per side with hose burst valve.
• Steps: Fitted to front corners with safety foot hold.
• L.E.D: Lamps Hella 2 side clearance lamps fitted 2 front top corner clearance lamps, 2 rear top red clearance lamps.

Optional Extras:

• Storage: A range of tool / storage boxes to your requirements.
• Tow Bars, Brake controllers, Voltage reducers.
• Tarp systems: Manual or motorised load covers.
• Safety: Flashing Beacons, Sign Boards, Arrow Boards.
• All Council specifications and requirements.
